M12 8 Pin Connector Manufacturing Company | High-Density Industrial Solutions
Pin Configuration: 5 Pin (A-Coded standard)
Gender: Male / Plug
Customization: Bespoke cable lengths (PUR/PVC) and wiring diagrams.
Ingress Protection: IP67 Waterproof.
Manufacturing Support: Factory direct supply with OEM/ODM capabilities.
M12 8 Pin Connector Manufacturing Company | High-Density Industrial Connectors
Premium M12 8-Pin Connectors for Complex Data & Signal Transmission
As a premier M12 8 pin connector manufacturing company, we specialize in high-density interconnect solutions designed for advanced industrial automation. Our M12 8 pin connector series balances compact design with robust performance, making it the industry standard for high-end sensors, encoders, and industrial Ethernet applications.
With IP67 waterproof protection and gold-plated contacts, these connectors provide zero-loss connectivity in demanding automated environments.
Key Features:
- Pin Count: 8 Pin (High-density configuration)
- Coding: A-Coded (Signal/Power) / X-Coded (High-speed Data)
- Standard: IEC 61076-2-101 / 109 compliant
- Quality: 100% Factory Tested & Certified
Technical Specifications
| Feature | Details |
|---|---|
| Product Type | M12 Circular Connector |
| Number of Positions | 8 Pins |
| Rated Voltage | 30V AC/DC |
| Rated Current | 2A |
| Contact Plating | Gold over Nickel (min. 500 mating cycles) |
| Housing Material | Nickel-plated Brass / Zinc Alloy / Stainless Steel |
| Insulation Resistance | ≥ 100 MΩ |
| Operating Temperature | -40°C to +85°C |
Why Choose Us
Precision Signal Integrity
High-density 8-pin configurations are prone to crosstalk and interference. Our M12 8 pin connector designs feature advanced internal shielding and precision-machined pins to ensure crystal-clear signal transmission for sensitive measuring instruments and high-speed data links.
Bespoke Manufacturing Capabilities
We are more than a standard supplier. Our team provides custom connector solutions, including:
- 360° EMI shielding
- Specialized PUR/PVC cable assemblies
- Unique overmolding for medical, marine, or industrial applications
Industrial-Grade Durability
Built for the factory floor, our connectors resist vibration, oils, chemicals, and extreme mechanical stress. The vibration-proof locking mechanism reduces downtime and maintenance costs for your automation infrastructure.
Key Applications
- Advanced Sensors: Multi-function sensors requiring high-pin count connections
- Vision Systems: Reliable data links for industrial cameras and imaging equipment
- Encoders & Feedback: Precise signal transmission for servo motors and motion control
- Industrial Ethernet: Supporting high-speed communication in smart factory networks
Ordering & Logistics
- Samples: Prototype samples available for technical evaluation
- Lead Time: Fast turnaround for standard stock and custom orders
- Global Support: Direct technical consultation and worldwide shipping from our China facility
