High power · mixed contact d-sub

Combo D-Sub High Power Connectors — Power & Signal, Mixed

The 8W8 combo D-Sub connector puts 8 power contacts and 8 signal contacts into one standard DB shell — one part, one panel cutout, one cable assembly instead of two.

Request a quote
View specifications

Contact layout

8W8

8 signal8 power

01 / 10

Product overview

A mixed-contact solution built for engineers who need both high-current power and control signal in a single interconnect.

The 8W8 Combo D-Sub High Power Connector combines 8 standard signal pins with 8 high-power contacts inside one compact D-Sub shell. The 8W8 layout is one of the most widely specified configurations within the broader family of combo D-Sub connectors, giving engineers a space-saving way to consolidate power and control lines that would otherwise need two separate connectors.

Built on a standard DB-size shell footprint, the 8W8 is a drop-in fit for existing panel cutouts and mounting hardware — a straightforward upgrade path for designs that need more power density without a full enclosure redesign. It shows up in industrial automation, power distribution units, motor drives, test equipment, and battery systems wherever a mixed power-and-signal interconnect is required.

As part of our high power D-Sub connector line, the 8W8 is built to tight tolerances with corrosion-resistant plating and precision-machined contacts for stable performance across repeated mating cycles and demanding electrical loads.

02 / 10

Key features

Mixed contact layout — 8 signal + 8 power contacts in one D-Sub shell
High current capacity — power contacts sized for motor, battery, and supply interconnects
Standard D-Sub footprint — fits common DB panel cutouts, jackscrews, hardware
Low-resistance plating — gold-flash plated contacts for stable, long-term conductivity
Rugged shell construction — zinc alloy or stainless steel, with EMI shielding
Flexible termination — solder cup, crimp, and PCB-mount options
Optional waterproof sealing — see our waterproof D-Sub connector series for IP-rated builds
Wide operating range — stable performance across harsh industrial environments

03 / 10

Technical specifications

Parameter	Specification
Contact arrangement	8 signal + 8 power contacts
Shell size	Standard D-Sub (DB) size
Shell material	Zinc alloy / stainless steel, plated
Contact material	Copper alloy, gold-flash plating
Insulator material	High-temperature thermoplastic
Current rating — power contacts	High-amperage per pin (config-dependent)
Current rating — signal contacts	Standard D-Sub signal rating
Dielectric withstanding voltage	Meets standard D-Sub HV requirements
Operating temperature	-55°C to +125°C typical
Mating cycles	500+ typical, plating-dependent
Termination types	Solder cup / crimp / PCB mount
Sealing (optional)	IP-rated waterproof variants available
Reference standards	MIL-DTL-24308-style construction, RoHS compliant materials

Exact ratings vary by pin configuration and plating option — contact our engineering team for application-specific data. For general D-Sub industry background, see TE Connectivity’s D-Sub connector overview.

04 / 10

Applications

The 8W8 combo connector is used wherever combined power and signal transmission needs to travel through a single interconnect:

Industrial automation and control panels
Motor drives and servo systems
Battery packs and energy storage systems
Power distribution units (PDUs)
Test and measurement equipment
Robotics and automated machinery
Medical equipment power/signal interfaces
Renewable energy systems

For outdoor or washdown-rated environments, pair this series with our waterproof D-Sub connector options for added ingress protection. Combo D-Sub layouts are also produced by other major connector manufacturers such as Phoenix Contact, reflecting how widely this mixed power/signal format is adopted across the industry.

05 / 10

Available options

Gender

Plug (male) and receptacle (female)

Mounting

Jackscrews, threaded inserts, or float mount

Plating

Gold-flash plated contacts

Shell finish

Nickel or other corrosion-resistant plating

Termination

Solder cup, crimp, or PCB mount

Sealing

Standard or waterproof / IP-rated

Need higher per-pin current than 8W8 provides? See the 17W2 High Current D-Sub Connector. Need a simpler power-only layout? Check the 3W3 High Power D-Sub Connector. For ultra-compact, high-density signal work, browse our Micro D connector line. And complete the assembly with parts from our D-Sub connector accessories range — backshells, hoods, jackscrews, and cable clamps.

06 / 10

Dimensions & downloads

2D / 3D drawings (DXF, STEP) Email to request
Product datasheet (PDF) Email to request
RoHS / REACH compliance certificates Email to request

For full mechanical drawings and CAD files, contact our sales engineering team at [email protected] or use the quote form below.

07 / 10

Key benefits

Space savings

Power and signal in one connector — less panel space, fewer cables.

Simplified assembly

Fewer connectors means faster wiring and fewer points of failure.

Proven reliability

Standard D-Sub shell design with a long track record in industrial use.

Flexible sourcing

Multiple plating, termination, and sealing options to match your project.

Cost efficiency

One part instead of two reduces BOM complexity and total system cost.

Broad compatibility

Fits the standard D-Sub cutouts and hardware already in your designs.

08 / 10

FAQ

What does “8W8” mean in the connector name?

It refers to the contact arrangement: 8 standard signal contacts combined with 8 power (“W”) contacts in a single D-Sub shell.

What is the maximum current rating of the 8W8 combo connector?

Current rating depends on the power contact and plating option selected. Contact our engineering team for the exact rating for your configuration.

Is the 8W8 combo connector waterproof?

Standard versions are not sealed. If IP-rated protection is required, see our waterproof D-Sub connector series or request a sealed variant.

Can the 8W8 connector be mounted using standard D-Sub panel cutouts?

Yes — the 8W8 uses a standard DB shell footprint, compatible with existing D-Sub panel cutouts and mounting hardware.

What termination options are available?

Solder cup, crimp, and PCB-mount terminations are all available depending on your assembly process.

Do you offer custom pin layouts or plating?

Yes — custom configurations, plating finishes, and mixed contact layouts can be produced on request. Contact us with your specifications.

Where can I find related high-power or high-current D-Sub options?

Explore our High Power D-Sub Connector category, or view the 17W2 High Current D-Sub Connector and 3W3 High Power D-Sub Connector pages for other power-focused configurations.

Request a quote

Send your pin configuration, current requirements, termination style, and quantity for the fastest response.
